Control Relay 4P 690V | 230V AC Coil | 2NO+2NC by Clipsal
Control relay with 4 poles (2NO+2NC) and 690V operational voltage—ideal for industrial machinery control circuits. Built for durability with 230V AC coil, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: TeSys K, Control Relay, 4P(2NO+2NC), 690V, 230V AC coil, without integral suppression device
Brand: Clipsal
SKU: CA2KN223P7
Alternatively Known As: TeSys Relay, Control Relay, 4 Pole Relay
Technical Specifications
- Rated operational voltage: <= 690V
- Coil voltage: 230V AC 50/60Hz
- Mechanical durability: 10 million cycles
- Insulation resistance: > 10 MOhm
- Operating temperature: -25 to 50 °C
- Inrush power: 30 VA
- Hold-in power consumption: 4.5 VA
- Maximum operating rate: 10,000 cycles/hour
- Dimensions (H x L x W): 58mm x 57mm x 45mm
- Weight: 0.18 kg
Key Features
- 4 poles with 2 normally open and 2 normally closed contacts.
- Rated operational voltage up to 690V.
- 230V AC coil for control circuit.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control circuits in machinery and equipment
Standards & Compliance
- Complies with EN/IEC 60947-4-1 for safety and performance standards.
Environmental Benefits
- Packaging made with recycled cardboard.
- Packaging without single-use plastic.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The TeSys K Control Relay is available now for immediate purchase. Ideal for industrial control applications.
