Control Relay CTX3 3NO1NC 415V AC | 3 Normally Open Contacts | DIN-Rail Mountable | High Endurance | @EA of 1 | by Legrand

BRAND: Legrand
SKU: 416819
$66.70 List price: $83.10
+ −
30 Days Return Delivery Options
Control relay CTX3 3NO1NC 415V AC is designed for reliable motor control and protection in industrial applications. Featuring 3 normally open contacts and 1 normally closed contact, this relay supports DIN-rail or screw mounting and boasts an impressive endurance of up to 20 million mechanical operations. Ideal for automation and control panels, it ensures optimal performance in tertiary electrical installations.

Product Name/Title: Control Relay CTX3 3NO1NC 415V AC | 3 Normally Open Contacts | DIN-Rail Mountable | High Endurance | @EA of 1 | by Legrand

Brand: Legrand

SKU: 416819

Alternatively Known As: Control relay 3NO1NC 415V, CTX3 relay, Legrand motor control relay

Technical Specifications
  • Rated control supply voltage AC 50 Hz: 340-440 V
  • Rated control supply voltage AC 60 Hz: 340-440 V
  • Voltage type for actuating: AC
  • Rated operation current Ie at 400 V: 1.9 A
  • Mounting method: DIN-rail or screw
  • Number of auxiliary contacts normally closed: 1
  • Number of auxiliary contacts normally open: 3
  • Connection type auxiliary circuit: Screw connection
  • Endurance: 20 million mechanical operations, 0.5 million electrical operations (AC-15)
  • Number of operation cycles (AC-3) per hour: 1800
  • Suitable for manual operation: Yes
  • With LED indication: No
  • Dimensions (H x L x W): 85mm x 60mm x 45mm
  • Weight: 0.3 kg
Key Features
  • 3 normally open (NO) and 1 normally closed (NC) main contacts
  • Screw terminals for power and coil connections
  • Expandable contact number with CTX3 mini auxiliary contact blocks
  • High endurance: up to 20 million mechanical operations and 0.5 million electrical operations (AC-15)
  • Designed for DIN-rail or screw mounting
  • Suitable for manual operation
  • Interface available
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and optimal performance.
Applications
  • Tertiary and industrial electrical installations
  • Motor control and protection systems
  • Automation and control panels
Standards & Compliance
  • AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
  • Designed with substance-restriction compliance
  • Manufactured through environmentally conscious processes
Warranty Information

Standard manufacturer warranty applies. Please refer to Legrand for specific warranty terms.

Available Now

Legrand Control Relay CTX3 3NO1NC 415V AC is available for immediate purchase, ideal for industrial and tertiary motor control applications.
