Control Station with Green Push-Button | IP66 Rated | Spring Return by Clipsal

BRAND: Clipsal
SKU: XALD103
$96.60 List price: $145.00
+
Control station with a green flush push-button marked 'START' and IP66 rating—ideal for industrial control applications. Built for durability with a spring return mechanism and polycarbonate housing.

Product Name/Title: Harmony XALD XALK, Control station, plastic, dark grey lid, 1 green flush push-button Ø22, spring return, marked START, 1 NO

Brand: Clipsal

SKU: XALD103

Alternatively Known As: Control Station, Push Button Station, Start Button Control Station

Technical Specifications
  • Rated operational current: 6 A at 120 V, 2 A at 600 V, 1 A at 600 V DC.
  • Electrical durability: 1,000,000 cycles.
  • Cable entry: 1 knock-out for cable entry, clamping capacity: 14-14 mm².
  • Material: Polycarbonate housing.
  • Operating temperature: -40 to 70 °C.
  • Vibration resistance: 5 gn (f= 12-500 Hz).
  • Shock resistance: 30 gn (duration = 18 ms).
  • Dimensions (H x L x W): 70mm x 98mm x 70mm
  • Weight: 0.156 kg
Key Features
  • Complete control station with a green flush push-button marked 'START'.
  • IP66, IP67, IP69K rated for high protection against dust and water.
  • Mechanical durability of 10 million cycles.
Professional Installation Requirements
  • Professional installation is recommended for optimal safety and functionality.
Applications
  • Industrial: Control and signaling applications in various environments.
Standards & Compliance
  • Complies with IEC 60947-5-1 for safety and performance standards.
Environmental Benefits
  • Packaging made with recycled cardboard and without single-use plastic.
Warranty Information

18 months warranty against manufacturing defects.

Available Now

The Clipsal Harmony XALD Control Station is available now for immediate purchase. Ideal for industrial control applications.

XALD103 (XALD103, 652 Kb) [Download]
