Copper Lug 185mm2 Cable | 20mm Stud | High Conductivity & Corrosion Resistant | AS4325 Compliant by Cabac
Cabac Copper Lug 185mm2 Cable with 20mm Stud is a high conductivity annealed copper crimp lug designed for reliable electrical connections, compliant with AS4325.1 and suitable for general purpose electrical applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Copper Lug 185mm2 Cable 20mm Stud
Brand: Cabac
SKU: CAL185-20
Alternatively Known As: Copper Cable Lug, Copper Crimp Lug, Electrical Cable Lug, Copper Terminal Lug, 185mm2 Copper Lug
Technical Specifications
- Material: 99.95% pure annealed copper
- Oxygen content: 30 ppm max
- Tensile strength: 200 MPa
- Ductility rating: 40%
- Electroplating: 99.9% pure tin with lead and antimony
- Total conductivity: 99.7% IACS
- Total resistivity: 1.738 micro-ohm cm
- Nominal conductor size: 185 mm²
- Stranding: 37 strands of 2.52 mm diameter
- Stud size: 20 mm
- ID size: 18.4 mm
- Torque recommendations: 5 mm thread - 5 Nm, 6 mm - 9 Nm, 8 mm - 22 Nm, 10 mm - 44 Nm, 12 mm - 77 Nm, 16 mm - 190 Nm
- Dimensions (H x L x W): n/a mm x 185mm x n/a mm
- Weight: 0.1 kg
Key Features
- Made from 99.9%+ high conductivity annealed copper for optimal electrical performance
- Electroplated with 99.9% pure tin with 5-10 microns thickness for corrosion resistance
- Compatible with standard Australian tooling and interchangeable with Utilux and Burndy tooling
- Complies with AS4325 Part 1 Australian standard and international standards IEC, DIN/VDE, JIS, BS, NEMA
- Recommended torque values provided for secure and safe connections
Professional Installation Requirements
- Installation should be performed by a qualified electrician using standard Australian crimping tools to ensure compliance and safety.
Applications
- Electrical power connectivity for industrial and commercial electrical installations
- General purpose crimp lugs for electrical wiring and cable terminations
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS4325 Part 1 Australia
Environmental Benefits
- High conductivity copper reduces energy loss in electrical systems
- Durable tin plating extends product life, reducing waste and replacement frequency
Warranty Information
Warranty details available upon request from the manufacturer.
Available Now
The Cabac Copper Lug 185mm2 Cable 20mm Stud is available for immediate purchase, ideal for electrical power connectivity and cable termination applications.
