Copper Reducer Bush 3/4 OD x 3/8 ID | Rated for CO2 60 Bar | ISO9001 Certified | by Aspen Pumps
The Copper Reducer Bush 3/4 OD x 3/8 ID is designed for high-pressure HVAC and refrigeration systems, rated for CO2 60 Bar and R-410A refrigerants. Manufactured in an ISO9001 accredited facility, it exceeds ISO/AS 5149.2 standards, ensuring safety and reliability in industrial and commercial piping installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Copper Reducer Bush 3/4 OD x 3/8 ID | Rated for CO2 60 Bar | ISO9001 Certified | by Aspen Pumps
Brand: Aspen Pumps
SKU: 100-1206
Alternatively Known As: Copper Reducer Bush, Copper Fitting Bush, HVAC Copper Bush, Refrigeration Copper Fitting
Technical Specifications
- Outer Diameter (OD): 3/4 inch
- Inner Diameter (ID): 3/8 inch
- Pressure Rating: CO2 60 Bar, R-410A high pressure
- Manufactured to exceed ISO/AS 5149.2 standards
- Manufactured in ISO9001 accredited facility
- Batch verification burst tested
- Recommended 15% silver solder for brazing in high pressure applications
- Dimensions (H x L x W): 20mm x 20mm x 20mm
- Weight: 0.1 kg
Key Features
- Rated for CO2 60 Bar and R-410A refrigerants
- Designed and tested to exceed ISO/AS 5149.2 standards
- Manufactured in ISO9001 accredited facility with rigorous QA including batch verification burst testing
- Marked fittings for safety with R-410A and HP-60 ratings
- Designed to remove stress and fatigue focus points
Professional Installation Requirements
- Installation should be performed by suitably qualified tradespeople following AS HB40 methodology; use 15% silver solder for brazing in high-pressure systems; ensure mechanical and thermal stresses are avoided in pipework design.
Applications
- HVAC systems requiring high-pressure copper fittings
- Refrigeration systems using R-410A and CO2 refrigerants
- Industrial and commercial piping installations
Standards & Compliance
- Complies with AS/NZS 5149.2 – Refrigerating systems and heat pumps – Safety and environmental requirements
Environmental Benefits
- Durable copper construction reduces need for frequent replacements
- Supports use in energy-efficient HVAC and refrigeration systems
Warranty Information
Warranty details available upon request from Aspen Pumps, typically covering manufacturing defects.
Available Now
The Aspen Pumps Copper Bush 3/4 OD x 3/8 ID is available for immediate purchase, ideal for HVAC and refrigeration system installations requiring high-pressure copper fittings.
