Copper Reducing Link 150sqmm Tinned Non-Insulated Wattmaster

BRAND: Alco
SKU: ALCLKR150-50
$124.30 List price: $165.80
+ −
30 Days Return Electricians Unlock Trade Access
Wattmaster copper reducing crimp link joins 150sqmm cable conductors of different sizes for reliable in-line connections.
Technical Specifications
  • Material: Electrolytic grade copper, electro-tin plated
  • Size Reduction: From 150mm² to 50mm²
  • Suitable for stranded and fine stranded copper conductors (class 2, 5, and 6)
  • Operating Temperature: -55°C to +155°C
  • Compliance: AS/NZS 4325.1:1995 (cl7) for sizes >10mm²
  • Dimensions (H x L x W): 10mm x 150mm x 50mm
  • Weight: 0.15 kg
Key Features
  • Uninsulated electrolytic grade copper crimp links for stranded and fine stranded copper conductors (class 2, 5, and 6)
  • Electro-tin plated for corrosion resistance
  • Chamfered ends for ease of entry of stranded conductors
  • Compatible with standard 6 tonne, 12 tonne, indent, and hex crimp tools
  • Operating temperature range from -55°C to +155°C
Professional Installation Requirements
  • Installation should be performed by a qualified electrician using appropriate crimping tools to ensure secure and compliant connections.
Applications
  • Electrical jointing of differing CSA conductors in residential, commercial, and industrial wiring
  • Suitable for use in electrical installations requiring reliable copper conductor connections
Standards & Compliance
  • Complies with AS/NZS 4325.1:1995 (cl7) for electrical connectors
Environmental Benefits
  • Electro-tin plating enhances longevity, reducing the need for frequent replacements and minimizing waste
Warranty Information

Warranty against manufacturing defects as per Wattmaster standard terms.

Available Now

Available for immediate purchase, ideal for electrical jointing applications requiring reliable copper conductor connections.
