Copper XLPE PVC Circular Cable 25mm | 0.6/1 kV Rated | Durable PVC Sheath | @M of 100 | by Electra Cables
Copper XLPE PVC Circular Cable 25mm is designed for efficient power distribution with a 0.6/1 kV voltage rating. Featuring a single core copper conductor and durable PVC sheath, this cable is ideal for both commercial and industrial applications, ensuring reliable performance in switchboards and control panels. Its XLPE insulation provides superior electrical and thermal performance, making it a top choice for underground and above-ground installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Copper XLPE PVC Circular Cable 25mm | 0.6/1 kV Rated | Durable PVC Sheath | @M of 100 | by Electra Cables
Brand: Electra Cables
SKU: XLPE1250-100BLK
Alternatively Known As: 25mm XLPE Cable, 25mm Single Core Power Cable, 25mm² Copper Cable, XLPE1250-100BLK, 0.6/1kV Power Cable
Technical Specifications
- Conductor: Plain annealed copper, 25mm²
- Insulation: Cross-linked Polyethylene (XLPE)
- Sheath: Polyvinyl Chloride (PVC), black
- Voltage Rating: 0.6/1kV
- Core: Single core
- Operating Temperature: -15°C to +90°C
- Compliance: AS/NZS 5000.1
- Flame retardant and UV resistant
- Dimensions (H x L x W): 15mm x 100000mm x 15mm
- Weight: 1.2 kg
Key Features
- 25mm² single core copper conductor for efficient current carrying capacity
- XLPE insulation for superior electrical and thermal performance
- Durable PVC sheath for enhanced mechanical protection and chemical resistance
- Rated for 0.6/1kV voltage applications
- Circular cable design for easy installation and flexibility
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Power distribution in commercial and industrial installations
- Suitable for fixed wiring in switchboards and control panels
- Ideal for underground and above-ground installations where mechanical protection is required
Standards & Compliance
- Complies with AS/NZS 5000.1 for power cables with extruded insulation and PVC sheath
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- XLPE insulation is halogen-free, reducing toxic emissions in case of fire
- Long service life reduces the need for frequent replacements
- Recyclable copper conductor
Warranty Information
12 months warranty against manufacturing defects.
Available Now
Available for immediate purchase. Ideal for commercial and industrial power distribution, switchboards, and control panels.
