Cordset Cable 6 Pin 22AWG | 4A 250V | IP69K Rated | PVC Yellow by NHP

BRAND: NHP
SKU: 889RF6ECA5
$101.20 List price: $134.40
+
Cordset cable with 6-pin micro female connector and 22AWG, rated for 4A and 250V—ideal for industrial and commercial applications. Built for durability, with IP69K protection and PVC yellow coating for reliable power connections.

Product Name/Title: AB 889R Cordset Cable PVC Yellow 6 Pin 22AWG AC Micro Female Straight Unshielded 50m

Brand: NHP

SKU: 889RF6ECA5

Alternatively Known As: 6 Pin Micro Female Cable, PVC Yellow Cordset, 22AWG AC Cable

Technical Specifications
  • Rated Current: 4 A
  • Rated Voltage: 250 V
  • Number of Poles: 6
  • Type of Plug: Female (bus)
  • Material Housing: Plastic
  • Coating Housing: Uncoated
  • Material Core Insulation: Other
  • Material of Contact Surface: Gold
  • Degree of Protection: IP69K
  • Mounting Method: Freely positionable
  • AWG Size: 22
  • Cable Diameter: 14 mm
  • Cable Length: 5000 mm
  • Operating Temperature: -20-105 °C
  • Dimensions (H x L x W): 14mm x 5000mm x 14mm
  • Weight: 1.5 kg
Key Features
  • 6-pin female connector for versatile applications.
  • Rated for 4A and 250V, suitable for various electrical needs.
  • IP69K rated for high protection against dust and water.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Machinery and equipment connections
  • Commercial: Electrical installations requiring durable cabling
  • General: Any application needing reliable power connections
Standards & Compliance
  • Complies with relevant Australian electrical safety standards.
Environmental Benefits
  • Durable materials reduce the need for frequent replacements.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The AB 889R Cordset Cable PVC Yellow 6 Pin 22AWG AC Micro Female Straight Unshielded 50m is available now for immediate purchase. Ideal for industrial and commercial applications.

889RF6ECA5-AU-PVC-Yellow-Cable-DC-Micro-M12-Datasheet.pdf (889RF6ECA5-AU-PVC-Yellow-Cable-DC-Micro-M12-Datasheet.pdf, 174 Kb) [Download]
