Core Color Sensor KTS-WB61141142ZZZZ | LED RGB Light Source | IP67 Rated | by SICK
The Core Color Sensor KTS-WB61141142ZZZZ features an LED RGB light source and is designed for precise color detection in industrial automation. With a sensing distance of up to 13 mm and a robust IP67 rated housing, it ensures reliable performance in quality control processes. Ideal for manufacturing environments, this sensor supports flexible configuration with 1-point and 2-point teach-in modes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10.8 V DC to 28.8 V DC
- Current consumption: less than 100 mA
- Switching frequency: 12.5 kHz
- Response time: 40 µs
- Light source: LED RGB with wavelengths 470 nm, 525 nm, 625 nm
- Light spot size: 1.2 mm x 3.9 mm
- Output function: Light/dark switching with push-pull PNP/NPN output
- Connection: Male connector M12, 4-pin
- Protection: Reverse polarity, short-circuit, interference pulse suppression
- Operating temperature: -20 °C to +60 °C
- Enclosure rating: IP67
- Dimensions (H x L x W): 62mm x 48mm x 26mm
- Weight: 0.1 kg
Key Features
- Core Color device type with LED RGB light source
- Sensing distance up to 13 mm with ±3 mm tolerance
- Light emission from the long side of housing with vertical light spot direction
- 1-point and 2-point teach-in modes for flexible configuration
- Push-pull PNP/NPN switching output with 100 mA max output current
- Adjustable delay time and light/dark switching output function
- Protection class III with reverse polarity and short-circuit protection
- IP67 rated housing for robust environmental protection
- Operating temperature range from -20 °C to +60 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and configuration.
Applications
- Color test applications requiring precise color detection
- Industrial automation and quality control processes
- Specialized sensing tasks in manufacturing environments
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP67 housing reduces need for frequent replacements
- Low current consumption (<100 mA) supports energy-efficient operation
- Long MTTFD of 291 years enhances reliability and reduces waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for detailed warranty terms.
Available Now
The SICK KTS-WB61141142ZZZZ Core Color Sensor is available for immediate purchase, ideal for industrial color testing and automation applications.
