Core Color Sensor KTS-WB71141142ZZZZ | IP67 Rated | LED RGB Light Source | 12.5 kHz Switching Frequency | by SICK
The Core Color Sensor KTS-WB71141142ZZZZ is designed for precise color detection in industrial automation and quality control applications. With an IP67 rated enclosure, it withstands harsh environments while offering a sensing distance of up to 13 mm. This sensor features a fast response time of 40 µs and a robust LED RGB light source, making it ideal for color test applications that require accuracy and reliability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10.8 V DC to 28.8 V DC
- Current consumption: less than 100 mA
- Switching frequency: 12.5 kHz
- Response time: 40 µs
- Output function: Light/dark switching with push-pull PNP/NPN output
- Output current max: 100 mA
- Protection class: III
- Connection type: Male connector M12, 4-pin
- Housing material: VISTAL®
- Optics material: COP
- Enclosure rating: IP67
- Operating temperature: -20 °C to +60 °C
- Storage temperature: -25 °C to +75 °C
- Shock load: 30 g / 11 ms according to IEC 60068-2-27
- Dimensions (H x L x W): 62mm x 48mm x 26mm
- Weight: 0.1 kg
Key Features
- Core Color device type with LED RGB light source
- Sensing distance up to 13 mm with ±3 mm tolerance
- Light emission from the long side of housing with vertical light spot direction
- 1-point and dynamic teach-in modes for easy setup
- Push-pull PNP/NPN switching output with 100 mA max output current
- IP67 rated enclosure for robust protection
- Operating temperature range from -20 °C to +60 °C
- Shock load resistance according to IEC 60068-2-27 (30 g/11 ms)
- Photobiological safety certified (IEC EN 62471)
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and configuration.
Applications
- Color test applications requiring precise color detection
- Industrial automation processes involving color sensing
- Quality control in manufacturing lines
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP67 housing reduces need for frequent replacements, minimizing waste
- Low current consumption (<100 mA) contributes to energy efficiency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK KTS-WB71141142ZZZZ Core Color Sensor is available for immediate purchase, ideal for industrial color testing and automation applications.
