Core Color Sensor KTS-WN61141142ZZZZ | RGB LED Light Source | IP67 Rated | by SICK
The Core Color Sensor KTS-WN61141142ZZZZ features an RGB LED light source and is designed for precise color detection in industrial automation and quality control applications. With a robust IP67 rated enclosure and flexible teach-in modes, it ensures reliable performance in challenging environments, making it ideal for specialized sensing tasks in manufacturing.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10.8 V DC to 28.8 V DC
- Current consumption: less than 100 mA
- Switching frequency: 12.5 kHz
- Response time: 40 µs
- Output type: NPN with max output current 100 mA
- Light source: RGB LED with wavelengths 470 nm, 525 nm, 625 nm
- Light spot size: 1.2 mm x 3.9 mm
- Teach-in modes: 1-point and 2-point
- Protection: Reverse polarity, short-circuit, interference pulse suppression
- Connection: Male M12, 4-pin connector
- Enclosure rating: IP67
- Operating temperature: -20 °C to +60 °C
- Storage temperature: -25 °C to +75 °C
- Shock resistance: 30 g/11 ms per IEC 60068-2-27
- Dimensions (H x L x W): 62mm x 48mm x 26mm
- Weight: 0.1 kg
Key Features
- Core Color device type with RGB LED light source
- Sensing distance up to 13 mm with ±3 mm tolerance
- Light emission from the long side of housing with vertical light spot direction
- 1-point and 2-point teach-in modes for flexible configuration
- Adjustable delay time and light/dark switching output function
- Protection class III with reverse polarity and short-circuit protection
- IP67 rated enclosure for robust environmental protection
- Operating temperature range from -20 °C to +60 °C
- Shock load resistance according to IEC 60068-2-27 (30 g/11 ms)
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connection and configuration.
Applications
- Color test applications requiring precise color detection
- Industrial automation and quality control
- Specialized sensing tasks in manufacturing environments
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable IP67 housing reduces need for frequent replacements
- Low current consumption (<100 mA) contributes to energy efficiency
- Non-volatile memory reduces waste by retaining settings without power
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK KTS-WN61141142ZZZZ Core Color Sensor is available for immediate purchase, ideal for industrial color testing and automation applications.
