Corrugated Conduit Fitting Nylon M16 Straight | IP66 Protection | Heat Shock & Flame Resistant | by Wattmaster
The Corrugated Conduit Fitting Nylon M16 Straight is designed for reliable electrical conduit termination, featuring IP66 protection and heat shock resistance. Ideal for industrial and commercial applications, this fitting ensures watertight connections and easy-click assembly, making it perfect for use in control panels and terminal boxes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Corrugated Conduit Fitting Nylon M16 Straight | IP66 Protection | Heat Shock & Flame Resistant | by Wattmaster
Brand: Wattmaster
SKU: ALCMIR-12M16N
Alternatively Known As: Nylon Corrugated Conduit Connector M16, Flexible Conduit Fitting M16, Nylon Cable Gland M16
Technical Specifications
- Material: High-quality polyamide (Nylon 6)
- Size: M16
- Protection Rating: IP66 or IP68/IP69K with sealing accessories
- Resistance: Heat shock resistant, flame resistant
- Assembly: Easy-click quick assembly and removal
- Locknuts: Sold separately
- Dimensions (H x L x W): 16mm x 40mm x 16mm
- Weight: 0.1 kg
Key Features
- Provides IP66 protection or IP68/IP69K protection with ORJ sealing ring and PLJ sealing washer
- Halogen, Phosphorus and Cadmium free
- Heat shock resistant and flame resistant
- Easy-click quick assembly and removal
- High tensile strength and watertight
- Self-extinguishing
- Manufactured from high-quality polyamide (Nylon 6)
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure proper sealing and compliance with electrical safety standards.
Applications
- Terminating ends of flexible corrugated conduits
- Cable entries on control panels
- Terminal boxes
- Electric motors
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen, Phosphorus and Cadmium free materials reduce environmental toxicity
- Durable and reusable design reduces waste
- Self-extinguishing properties enhance safety and reduce fire risk
Warranty Information
Standard manufacturer warranty applies; typically 1 year against manufacturing defects.
Available Now
The Wattmaster Corrugated Conduit Fitting Nylon M16 Straight is available for immediate purchase, ideal for electrical conduit termination in industrial and commercial applications.
