Corrugated Conduit Fitting Nylon M25 90Deg | IP66 Rated | Easy-Click Assembly | by Wattmaster
The Corrugated Conduit Fitting Nylon M25 90Deg is designed for seamless connections in industrial and commercial electrical installations. Made from high-quality polyamide (Nylon 6), it features an IP66 protection rating and a temperature range of -40°C to +105°C. With its easy-click assembly, this fitting ensures quick and reliable installation, making it ideal for terminating flexible conduits to control panels and terminal boxes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Corrugated Conduit Fitting Nylon M25 90Deg | IP66 Rated | Easy-Click Assembly | by Wattmaster
Brand: Wattmaster
SKU: ALCNEC-23M25N
Alternatively Known As: Nylon Corrugated Conduit Elbow, Flexible Conduit Connector, Nylon 90 Degree Conduit Fitting, M25 Nylon Conduit Elbow
Technical Specifications
- Material: Polyamide (Nylon 6)
- Size: M25
- Angle: 90 degrees
- Protection Rating: IP66 or IP68/IP69K with sealing ring and washer
- Temperature Range: -40°C to +105°C (150°C short term)
- Flame Resistance: Self-extinguishing
- Assembly: Easy-click quick assembly and removal
- Locknuts: Sold separately
- Dimensions (H x L x W): 30mm x 40mm x 30mm
- Weight: 0.1 kg
Key Features
- Manufactured from high-quality polyamide (Nylon 6)
- IP66 protection or IP68/IP69K protection with ORJ sealing ring and PLJ sealing washer
- Halogen, Phosphorus and Cadmium free
- Heat shock resistant and flame resistant
- Self-extinguishing
- “Easy-click” quick assembly and removal
- High tensile strength and watertight
- Locknuts sold separately
- Temperature range: -40°C to +105°C (150°C short term)
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and proper sealing.
Applications
- Terminating ends of flexible corrugated conduits to cable entries on control panels
- Terminal boxes
- Electric motors
- Industrial and commercial electrical installations requiring conduit fittings
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen, Phosphorus and Cadmium free materials reduce environmental toxicity
- Durable and long-lasting design reduces waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies. Please refer to Wattmaster warranty policy for details.
Available Now
The Wattmaster Corrugated Conduit Fitting Nylon M25 90Deg is available for immediate purchase, ideal for industrial and commercial electrical conduit installations.
