Corrugated Conduit Fitting Nylon M50 90Deg | IP66 Protection | Easy-Click Assembly | by Wattmaster
The Corrugated Conduit Fitting Nylon M50 90Deg is designed for seamless connections in industrial and commercial electrical installations. Made from high-quality polyamide (Nylon 6), it features IP66 protection and a temperature range of -40°C to +105°C. With its easy-click assembly, this fitting ensures a secure and watertight connection, making it ideal for terminating flexible conduits to control panels and terminal boxes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Corrugated Conduit Fitting Nylon M50 90Deg | IP66 Protection | Easy-Click Assembly | by Wattmaster
Brand: Wattmaster
SKU: ALCNEC-48M50N
Alternatively Known As: Nylon Corrugated Conduit Fitting 50mm 90 Degree, Nylon Conduit Elbow, Flexible Conduit Connector, Nylon Cable Gland Elbow
Technical Specifications
- Material: Polyamide (Nylon 6)
- Size: M50 (50mm)
- Angle: 90 degrees
- Protection Rating: IP66 or IP68/IP69K with sealing ring and washer
- Temperature Range: -40°C to +105°C (150°C short term)
- Flame Resistance: Self-extinguishing
- Assembly: Easy-click quick assembly and removal
- Locknuts: Sold separately
- Dimensions (H x L x W): 70mm x 70mm x 70mm
- Weight: 0.1 kg
Key Features
- Manufactured from high-quality polyamide (Nylon 6)
- IP66 protection or IP68/IP69K protection with ORJ sealing ring and PLJ sealing washer
- Halogen, Phosphorus and Cadmium free
- Heat shock resistant and flame resistant
- Self-extinguishing
- “Easy-click” quick assembly and removal
- High tensile strength and watertight
- Locknuts sold separately
- Temperature range: -40°C to +105°C (150°C short term)
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure proper sealing and compliance with electrical safety standards.
Applications
- Terminating ends of flexible corrugated conduits to cable entries on control panels
- Terminal boxes
- Electric motors
- Industrial and commercial electrical installations requiring conduit fittings
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen, Phosphorus and Cadmium free materials reduce environmental toxicity
- Durable and long-lasting design reduces waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; typically 1 year against manufacturing defects.
Available Now
The Wattmaster Corrugated Conduit Fitting Nylon M50 90Deg is available for immediate purchase, ideal for industrial and commercial electrical conduit installations.
