Corrugated Conduit Tubing Holder Nylon 20mm | Self-Extinguishing | Shock-Resistant | @Each by Wattmaster
The Corrugated Conduit Tubing Holder Nylon 20mm is designed for secure mounting of ALCAGT conduits, featuring a self-extinguishing and shock-resistant design. Ideal for electrical installations in residential, commercial, and industrial settings, this holder is made from specially modified polyamide (PA6) for enhanced durability and safety, ensuring compliance with AS/NZS 3000 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Corrugated Conduit Tubing Holder Nylon 20mm | Self-Extinguishing | Shock-Resistant | @Each by Wattmaster
Brand: Wattmaster
SKU: ALCSWL-17N
Alternatively Known As: Nylon Conduit Holder 20mm, Corrugated Tubing Clamp, PA6 Conduit Support
Technical Specifications
- Material: Specially modified polyamide (PA6)
- Suitable for: 20mm corrugated conduit (ALCAGT)
- Temperature range: -40ºC to +105ºC (150ºC short term)
- Self-extinguishing and shock-resistant
- Includes integrated lid for conduit protection
- Dimensions (H x L x W): 25mm x 40mm x 30mm
- Weight: 0.1 kg
Key Features
- Mounting support with integrated lid suitable for corrugated conduit
- Free of halogen, phosphorus, and cadmium for safety
- Self-extinguishing material enhances fire safety
- Shock-resistant design for durability
- Temperature range from -40ºC to +105ºC, with short-term tolerance up to 150ºC
- Made of specially modified polyamide (PA6) for strength and longevity
Professional Installation Requirements
- Installation by a qualified electrician or trained professional is recommended to ensure secure mounting and compliance with electrical standards.
Applications
- Electrical installations requiring secure mounting of corrugated conduits
- Industrial and commercial wiring setups
- Non-metallic conduit support in residential and commercial buildings
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Free from halogen, phosphorus, and cadmium, reducing environmental toxicity
- Durable and shock-resistant design extends product life, reducing waste
Warranty Information
Standard manufacturer warranty against defects applies; please refer to Wattmaster for specific terms.
Available Now
The Wattmaster Corrugated Conduit Tubing Holder Nylon 20mm is available for immediate purchase, ideal for electrical conduit mounting in residential, commercial, and industrial applications.
