Countersink Drill Bit | 12.4mm Spot-Facer | HSS Material | 90 Degree Angle | by Wurth
The Countersink Drill Bit is designed for burr- and chatter-free countersinking and deburring, making it ideal for machining conventional steels, cast iron, and non-ferrous metals like aluminum and copper. With a 12.4mm spot-facer diameter and optimized geometry for hand-held tools, this bit ensures no slipping in the drill chuck and allows for rapid changes between countersinking and screwing, perfect for trained operators.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Countersink Drill Bit | 12.4mm Spot-Facer | HSS Material | 90 Degree Angle | by Wurth
Brand: Wurth
SKU: 694025012
Alternatively Known As: Countersink drill bit, Deburring tool, Countersinking cutter, Hand-held countersink
Technical Specifications
- Material to be processed: Non-ferrous metal, Steel
- Quality: ZEBRA-Premium
- Spot-facer diameter (d1): 12.4 mm
- Shank diameter (d2): 1/4 inch
- Tip diameter (d3): 2.8 mm
- Length (l1): 34 mm
- Number of cutting edges (Z): 3 PCS
- Cutting material: HSS
- Countersink angle: 90 Degree
- Surface: Plain
- Service life (points system): 2 of 4 points
- Countersinking speed (points system): 2 of 4 points
- Countersinking quality (points system): 3 of 4 points
- Versatility (points system): 2 of 4 points
- Countersinking behaviour (points system): 3 of 4 points
- Material of sub-group: General structural steels, Non-alloyed tempering steels, Alloyed tempering steels, High-speed steels, Nitriding steels, Tool steels, Cast iron, Ductile iron, Malleable cast iron, Aluminium, Aluminium wrought alloys, Aluminium alloys, White cast iron, Aluminium casting alloys (<10% silicon), Aluminium casting alloys (>10% silicon), Magnesium alloys, Copper, low-alloyed, Brass, short-chipping, Brass, long-chipping, Bronze, short-chipping, Bronze, long-chipping, Plastics, thermoset, Plastics, thermoplastic, Plastics, aramide-fibre reinforced, Plastics, glass/carbon-fibre-reinforced
- Dimensions (H x L x W): 34mm x 34mm x 6mm
- Weight: 0.1 kg
Key Features
- Burr- and chatter-free countersinking and deburring
- No slipping in the drill chuck, suitable for bit holders
- Rapid change between countersinking and screwing possible
- Optimised geometry for hand-held tools
- Standardised 1/4 inch hexagon shank
- Product packaging made from 100% PCR (recycled plastic from household waste) and 100% recyclable
Professional Installation Requirements
- No professional installation required; suitable for use with hand-held machines by trained operators.
Applications
- Machining conventional steels
- Machining cast iron
- Machining non-ferrous metals such as aluminium, copper, aluminium alloys
- Machining plastics with hand-held machines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Product packaging made from 100% recycled plastic from household waste
- 100% recyclable packaging reduces environmental impact
Warranty Information
Standard manufacturer warranty applies.
Available Now
The Wurth Countersink Tool is available now for immediate purchase. Ideal for machining applications involving conventional steels, cast iron, and non-ferrous metals.
