Crimp Cable Lug Fork Shape | Polyamide Insulated | M5 Flange Hole | Red | @Pack of 25 | by Wurth
Crimp Cable Lug Fork Shape with polyamide insulation and M5 flange hole—ideal for secure electrical connections. Designed for automotive, industrial, and residential applications, this lug ensures reliable terminations even in fluctuating temperatures. The halogen-free and silicone-free materials enhance safety and environmental sustainability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Crimp Cable Lug Fork Shape | Polyamide Insulated | M5 Flange Hole | Red | @Pack of 25 | by Wurth
Brand: Wurth
SKU: 5589202
Alternatively Known As: Crimp Fork Terminal, Polyamide Insulated Cable Lug, Fork Tongue Connector, Electrical Fork Terminal
Technical Specifications
- Min./max. wire cross section: 0.25-1.65 mm²
- Colour: Red
- Flange hole: M5
- Length: 22 mm
- Max. nominal voltage: 600 V/AC
- Max. temperature conditions: 105 °C
- Material: Copper
- Surface: Tin plated
- Insulating material: Nylon
- Halogen-free: Yes
- Silicone-free: Yes
- Dimensions (H x L x W): 22mm x 22mm x 10mm
- Weight: 0.02 kg
Key Features
- Expanded insulating sleeve for easy and safe conductor insertion
- High-quality polyamide insulation suitable for temperature fluctuations
- Fork shape in accordance with DIN 46237/C
- Strong cable core insulation allowing easy processing
- Halogen-free and silicone-free nylon insulating material
- Tin plated copper surface for corrosion resistance
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure proper crimping and secure electrical connections.
Applications
- Electrical wiring and connections in automotive, industrial, and residential applications
- Suitable for use in environments with changing loads and temperature fluctuations
- Ideal for secure and reliable cable terminations requiring fork-shaped lugs
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen-free and silicone-free materials reduce environmental impact
- Durable tin-plated copper surface extends product life and reduces waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth's warranty policy for details.
Available Now
Wurth Crimp Cable Lug Fork Shape Polyamide Insulated M5 25 PCS is available for immediate purchase, ideal for electrical wiring and connection applications requiring reliable and safe cable terminations.
