PL 12 / 25 Crimp & Insul Set 6P 120 mm^2

Crimp & Insul Set 6P 120 mm² | 660V to 3300V | IP55 Rated | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1948

$279.10 List price: $346.70

+ −

30 Days Return Delivery Options

The Crimp & Insul Set 6P 120 mm² is designed for hazardous environments, featuring a voltage range of 660V to 3300V and IP55 ingress protection. Ideal for mining and tunnelling applications, it offers quick release functionality and durable stainless steel construction for reliable performance.

Description

Product Name/Title: PL 12 / 25 Crimp & Insul Set 6P 120 mm^2

Brand: Ausproof

SKU: RS1948

Alternatively Known As: Ex-certified plug and receptacle set, Flameproof plug and socket, Mining electrical connector, Hazardous area plug, Stainless steel industrial plug

Technical Specifications

Voltage range: 660V to 3300V
Current ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature rise ratings for 300A and 425A
Compliant to AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 200mm x 400mm x 300mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Professional installation by qualified personnel trained in hazardous area electrical equipment is required to ensure safety and compliance.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairable design minimizes waste by allowing on-site body casting replacement

Warranty Information

Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.

Available Now

The Ausproof PL 12 / 25 Crimp & Insul Set 6P 120 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring robust and flameproof electrical connectors.
