Home/Electrical/Industrial/Industrial Outlets/Crimp & Insulated Set 6P 95 mm² | 660V to 3300V | IP55 Ingress Protection | Quick Release by Ausproof

Trade Discount 19%

Crimp & Insulated Set 6P 95 mm² | 660V to 3300V | IP55 Ingress Protection | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1956

$279.10 List price: $346.70

+ −

30 Days Return Delivery Options

The Crimp & Insulated Set 6P 95 mm² is designed for high voltage applications, featuring a voltage range of 660V to 3300V and IP55 ingress protection. Ideal for mining and tunnelling, this durable set ensures reliable performance with quick release and stainless steel construction.

Description

Product Name/Title: PL 16 / 25 Crimp & Insul Set 6P 95 mm^2

Brand: Ausproof

SKU: RS1956

Alternatively Known As: PL Range Crimp & Insulated Set, Ex-certified Industrial Plug, Mining Plug and Receptacle, Flameproof Electrical Connector

Technical Specifications

Voltage Range: 660V to 3300V
Current Ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Compliance: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 150mm x 300mm x 200mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by qualified personnel trained in hazardous area electrical equipment installation to ensure compliance with safety standards.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

AS/NZS 1299 – Electrical Equipment in Hazardous Areas

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairable design minimizes waste by allowing on-site body casting replacement

Warranty Information

Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.

Available Now

The Ausproof PL 16 / 25 Crimp & Insul Set 6P 95 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring robust and flameproof electrical connectors.
