PL 12 / 25 Crimp & Insul Set 4P 150 mm^2

Crimp & Insulation Set 4P 150 mm² | 660V to 3300V | IP55 Rated | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1967

$253.00 List price: $314.20

+ −

30 Days Return Delivery Options

The Crimp & Insulation Set 4P 150 mm² is designed for high voltage applications, featuring a voltage range of 660V to 3300V and IP55 ingress protection. Ideal for mining and tunnelling, this durable set ensures easy termination and flameproof repairs, making it perfect for hazardous environments.

Description

Product Name/Title: PL 12 / 25 Crimp & Insul Set 4P 150 mm^2

Brand: Ausproof

SKU: RS1967

Alternatively Known As: PL Range Crimp and Insulation Set, Ex-certified Mining Plug, Flameproof Electrical Connector, Heavy Duty Industrial Plug

Technical Specifications

Voltage Range: 660V to 3300V
Current Ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Weight: Receptacle 10.7 kg, Plug 9.0 kg
Dimensions (H x L x W): 150mm x 150mm x 250mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation and maintenance should be performed by qualified personnel trained in hazardous area electrical equipment to ensure safety and compliance.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment in Hazardous Areas

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairable design minimizes waste by allowing on-site repairs

Warranty Information

Standard manufacturer warranty applies. Please contact Ausproof for detailed warranty terms.

Available Now

The Ausproof PL 12 / 25 Crimp & Insul Set 4P 150 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and commercial hazardous environment applications.
