Crimp & Insulation Set 4P 185 mm² | 660V to 3300V | IP55 Rated | Quick Release by Ausproof
The Crimp & Insulation Set 4P 185 mm² is designed for high voltage applications, supporting a voltage range of 660V to 3300V and featuring IP55 ingress protection. Ideal for mining and tunnelling, this set ensures robust and flameproof electrical connections with easy termination and quick release functionality.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PL 19 / 25 Crimp & Insul Set 4P 185 mm^2
Brand: Ausproof
SKU: RS1924
Alternatively Known As: PL Range Crimp and Insulation Set, Ex-certified Industrial Plug, Flameproof Electrical Connector, Mining Grade Plug and Receptacle
Technical Specifications
- Voltage Range: 660V to 3300V
- Current Ratings: 300A and 425A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
- Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
- AC High Voltage Withstand (Phase): 8.6kV for one minute
- AC High Voltage Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: Rated for 300A and 425A
- Plug Weight: 9.0 kg
- Receptacle Weight: 10.7 kg
- Dimensions (H x L x W): 185mm x 185mm x 185mm
- Weight: 10.7 kg
Key Features
- Quick Release
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Installation must be performed by qualified personnel trained in hazardous area electrical equipment installation to ensure compliance with safety standards and proper flameproof assembly.
Applications
- Mining
- Tunnelling
- Commercial applications
- Group 1 hazardous environments
Standards & Compliance
- Complies with AS/NZS 1299 – Electrical Equipment in Hazardous Areas
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacements.
- Flameproof repairability reduces waste by allowing on-site repairs without full replacement.
Warranty Information
Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.
Available Now
The Ausproof PL 19 / 25 Crimp & Insul Set 4P 185 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial environments requiring robust and flameproof electrical connections.
