Making Trade Life Easy!

Home/Electrical/Industrial/Industrial Outlets/Crimp & Insulation Set 4P 185 mm² | 660V to 3300V | IP55 Rated | Quick Release by Ausproof

Trade Discount 19%

PL 12 / 25 Crimp & Insul Set 4P 185 mm^2

Crimp & Insulation Set 4P 185 mm² | 660V to 3300V | IP55 Rated | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1968

$253.00 List price: $314.20

+ −

30 Days Return Delivery Options

The Crimp & Insulation Set 4P 185 mm² is designed for high voltage applications, operating between 660V to 3300V with an IP55 rating. Ideal for mining and commercial use, it features quick release and durable stainless steel construction for reliable performance in hazardous environments.

Description

Product Name/Title: PL 12 / 25 Crimp & Insul Set 4P 185 mm^2

Brand: Ausproof

SKU: RS1968

Alternatively Known As: PL Range Crimp and Insulation Set, Ex-certified Industrial Plug, Flameproof Plug and Receptacle, Mining Electrical Connector

Technical Specifications

Operating Voltage: 660V to 3300V
Current Ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Configurations: 4-pin or 6-pin available
Compliance: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 185mm x 185mm x 185mm
Weight: 9 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Professional installation by qualified personnel trained in hazardous area electrical equipment is required to ensure safety and compliance.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 for electrical equipment in hazardous areas

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairable design minimizes waste by allowing on-site body casting replacement

Warranty Information

Warranty information not specified; please contact Ausproof for details.

Available Now

The Ausproof PL 12 / 25 Crimp & Insul Set 4P 185 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and commercial hazardous environment applications.
