Crimp Terminal Non-Insulated Quick Disconnect | 1.5-2.5MM² Compatibility | Brass with Electro Tinned Finish | by Wattmaster
Crimp Terminal Non-Insulated Quick Disconnect is designed for reliable electrical connections, compatible with 1.5-2.5 mm² cables. Made from brass with an electro tinned finish, these terminals enhance conductivity and corrosion resistance, making them ideal for automotive, industrial, and household applications. Easy to connect and disconnect, they are available in both male and female configurations for versatile use.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Crimp Terminal Non-Insulated Quick Disconnect | 1.5-2.5MM² Compatibility | Brass with Electro Tinned Finish | by Wattmaster
Brand: Wattmaster
SKU: ALCFQDU2/100
Alternatively Known As: Quick Disconnect Terminal, Non-Insulated Crimp Terminal, Quick Connect Terminal, Electrical Disconnect Terminal
Technical Specifications
- Terminal Type: Non-insulated quick disconnect
- Cable Size Compatibility: 1.5-2.5 mm²
- Terminal Width: 2.8 mm
- Terminal Thickness: 0.5 mm
- Material: Brass with electro tinned finish
- Configurations: Male and female
- Dimensions (H x L x W): 0.5mm x 15mm x 2.8mm
- Weight: 0.1 kg
Key Features
- Non-insulated brass terminals for reliable conductivity
- Suitable for stranded to fine-stranded cable
- Electro tinned finish enhances conductivity and corrosion resistance
- Easy to connect and disconnect
- Available in male and female configurations
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure proper crimping and electrical safety.
Applications
- Electrical wiring connections for automotive, industrial, and household applications
- Suitable for use in control panels and electrical equipment requiring quick disconnect terminals
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Electro tinned finish improves terminal lifespan reducing waste
- Reusable quick disconnect design reduces need for replacement parts
Warranty Information
Standard manufacturer warranty applies. Please refer to Wattmaster warranty policy for details.
Available Now
Wattmaster Crimp Terminal Non-Insulated Quick Disconnect 1.5-2.5MM² is available for immediate purchase, ideal for electrical wiring and quick disconnect applications.
