Cylinder Position Sensor MPS-064TLTQ0 | 64 mm Measuring Range | IO-Link V1.1 | IP67 Rated | by SICK
The Cylinder Position Sensor MPS-064TLTQ0 is designed for precise cylinder position measurement in industrial automation. With a measuring range of 64 mm and a high resolution of 0.03% FSR, it ensures accurate readings in harsh environments. Featuring an IO-Link V1.1 communication interface and an IP67 rated enclosure, this sensor is perfect for applications requiring reliable performance and durability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: 64 mm
- Housing length: 77 mm
- Output function: IO-Link V1.1
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 25 mA without load
- Protection class: III
- Resolution: 0.03% FSR (max. ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Operating temperature: -20°C to +70°C
- Shock resistance: 30 g, 11 ms
- Vibration resistance: 10-55 Hz, 1 mm
- Connection: Cable with M12 male connector, 4-pin, 0.3 m
- Cable diameter: 2.6 mm
- Bending radius: >5x cable diameter fixed, >10x flexible
- Material: Plastic housing, PUR cable
- Status indicator LED: Yes
- Reverse polarity and short-circuit protection: Yes
- Dimensions (H x L x W): 20mm x 77mm x 20mm
- Weight: 0.1 kg
Key Features
- T-slot cylinder type compatible with various cylinder adapters
- Measuring range of 64 mm with high resolution of 0.03% FSR
- IO-Link communication interface V1.1 with COM2 and 2.3 ms cycle time
- IP67 rated enclosure for dust and water protection
- Electrical wiring: DC 4-wire with reverse polarity and short-circuit protection
- Status indicator LED and teach-in functionality for easy setup
- Operating temperature range from -20°C to +70°C
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Cable with M12 male connector, 4-pin, 0.3 m length
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper electrical connection and sensor calibration.
Applications
- Industrial automation for precise cylinder position measurement
- Use with round body, profile, tie-rod, dovetail groove cylinders
- Suitable for harsh environments requiring IP67 protection
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient operation with low power consumption (25 mA)
- Durable IP67 housing reduces waste by extending product lifespan
- Supports predictive maintenance via IO-Link to reduce downtime and resource use
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-064TLTQ0 Cylinder Position Sensor is available for immediate purchase, ideal for industrial automation and precise cylinder position monitoring.
