Cylinder Position Sensor MPS-096TLTQ0 | 96 mm Measuring Range | IO-Link V1.1 | IP67 Rated | by SICK
The Cylinder Position Sensor MPS-096TLTQ0 is designed for precise cylinder position measurement in industrial automation. With a measuring range of 96 mm and a high resolution of 0.03% FSR, it ensures accurate sensing in demanding environments. Featuring an IP67 rated enclosure and IO-Link V1.1 communication, this sensor is perfect for factory automation applications requiring robust and reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: 96 mm
- Housing length: 109 mm
- Output function: IO-Link V1.1
- Electrical wiring: DC 4-wire
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 25 mA without load
- Protection class: III
- Resolution: 0.03% FSR (max. ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Operating temperature: -20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10-55 Hz, 1 mm
- Connection type: Cable with M12 male connector, 4-pin, 0.3 m
- Material: Plastic housing, PUR cable
- Status indicator LED: Yes
- Reverse polarity and short-circuit protection: Yes
- Dimensions (H x L x W): 20mm x 109mm x 20mm
- Weight: 0.2 kg
Key Features
- T-slot cylinder type compatible with round body, profile, tie-rod, dovetail groove cylinders and SMC rails
- Measuring range of 96 mm with high resolution of 0.03% FSR
- IO-Link V1.1 communication interface with COM2 and 2.3 ms cycle time
- IP67 rated enclosure for protection against dust and water
- Electrical wiring: DC 4-wire with reverse polarity and short-circuit protection
- Status indicator LED and teach-in functionality for easy adjustment
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Operating temperature range from -20 °C to +70 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connection and sensor calibration.
Applications
- Industrial automation for precise cylinder position measurement
- Factory automation requiring robust and accurate sensing
- Use in environments needing IP67 rated sensors with IO-Link communication
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption of 25 mA reduces energy usage
- Durable IP67 housing extends product life and reduces waste
- Supports IO-Link for efficient data communication and system integration
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-096TLTQ0 T-slot Cylinder Position Sensor is available for immediate purchase, ideal for industrial automation and factory applications requiring precise position sensing.
