Cylinder Position Sensor MPS-128TLTQ0 | IO-Link Compatible | IP67 Rated | 128mm Measuring Range | by SICK
The Cylinder Position Sensor MPS-128TLTQ0 is designed for precise position measurement in industrial automation. With a measuring range of 128 mm and IP67 rating for dust and water protection, this sensor is perfect for factory automation applications. It features IO-Link communication for efficient data transfer and robust performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Dimensions (H x L x W): 20mm x 141mm x 20mm
- Weight: 0.3 kg
Key Features
- T-slot cylinder type compatible with round body, profile, tie-rod, dovetail groove cylinders and SMC rails
- Measuring range of 128 mm
- Output function via IO-Link with standard functions
- Electrical wiring: DC 4-wire
- Enclosure rating IP67 for dust and water protection
- Adjustment via teach-in control panel with key lock and factory reset
- Supply voltage range 15 V DC to 30 V DC
- Power consumption 25 mA without load
- Protection class III with reverse polarity and short-circuit protection
- Status indicator LED and teach-in functionality
- Operating temperature range from -20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- Communication interface IO-Link V1.1 with COM2 and 2.3 ms cycle time
- Process data length 16 Bit with position data structure
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical wiring and configuration of IO-Link communication.
Applications
- Industrial automation for precise cylinder position measurement
- Factory automation requiring robust and accurate position sensing
- Use in environments needing IP67 rated sensors with IO-Link communication
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption of 25 mA reduces energy usage
- Durable IP67 rated housing extends product life and reduces waste
- Supports IO-Link communication for efficient data transfer and system integration
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-128TLTQ0 IO-Link T-slot Cylinder Position Sensor is available for immediate purchase, ideal for industrial automation and factory equipment requiring precise position measurement.
