Cylinder Position Sensor MPS-128TSNP0 | 128 mm Measuring Range | Analog Output Options | IP67 Rated | by SICK
The Cylinder Position Sensor MPS-128TSNP0 is designed for precise cylinder position measurement in industrial automation. With a measuring range of 128 mm and analog output options of 0 V to 10 V or 4 mA to 20 mA, it ensures reliable feedback for factory automation. Its IP67 rated enclosure provides dust and water protection, making it ideal for various applications, including use with round body and profile cylinders.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cylinder Position Sensor MPS-128TSNP0 | 128 mm Measuring Range | Analog Output Options | IP67 Rated | by SICK
Brand: SICK
SKU: 1053838
Alternatively Known As: Cylinder Position Sensor, Analog Cylinder Sensor, T-slot Position Sensor, SICK MPS Sensor
Technical Specifications
- Measuring range: 128 mm
- Housing length: 141 mm
- Output function: Analog (0 V ... 10 V or 4 mA ... 20 mA)
- Electrical wiring: DC 4-wire
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 22 mA without load
- Max load resistance: ≤ 500 Ω at 24 V
- Min load resistance: ≥ 2 kΩ
- Protection class: III
- Time delay before availability: 1.5 s
- Magnetic field sensitivity: 4 mT to 30 mT
- Resolution: 0.03% FSR (max. ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Reverse polarity and short-circuit protection: Yes
- Status indicator LED: Yes
- Operating temperature: -20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10-55 Hz, 1 mm
- EMC compliance: EN 60947-5-7
- Connection type: Cable with M8 male connector, 4-pin, 0.3 m
- Cable specifications: PUR, 0.08 mm² conductor cross section, 2.6 mm diameter
- Dimensions (H x L x W): 20mm x 141mm x 20mm
- Weight: 0.2 kg
Key Features
- T-slot cylinder type compatible with various cylinder adapters
- Measuring range of 128 mm
- Analog output options: 0 V to 10 V voltage or 4 mA to 20 mA current
- DC 4-wire electrical wiring
- IP67 rated enclosure for dust and water protection
- Supply voltage range from 15 V DC to 30 V DC
- Low power consumption of 22 mA without load
- Reverse polarity and short-circuit protection
- Status indicator LED included
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Operating temperature range from -20 °C to +70 °C
- Cable with M8 male connector, 4-pin, 0.3 m length
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and compliance with safety standards.
Applications
- Industrial automation for cylinder position measurement
- Factory automation requiring precise analog position feedback
- Use with round body, profile, tie-rod, dovetail groove cylinders and SMC rails
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP67 housing reduces replacement frequency and waste
- Low power consumption contributes to energy efficiency
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-128TSNP0 Analog T-slot Cylinder Position Sensor is available for immediate purchase, ideal for industrial automation and precise cylinder position measurement applications.
