Cylinder Position Sensor MPS-256TLTQ0 | 256 mm Measuring Range | IO-Link V1.1 Output | IP67 Rated | by SICK
The Cylinder Position Sensor MPS-256TLTQ0 is designed for precise linear position measurement in industrial automation. With a measuring range of 256 mm and an IO-Link V1.1 output function, it ensures reliable performance in demanding environments. Its IP67 rated enclosure provides excellent dust and water protection, making it ideal for factory automation applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: 256 mm
- Housing length: 269 mm
- Output function: IO-Link V1.1, COM2, cycle time 2.3 ms
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 25 mA without load
- Protection class: III
- Resolution: 0.03% FSR (max. ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Operating temperature: -20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm
- Connection: Cable with M12 male connector, 4-pin, 0.3 m, PUR cable
- Enclosure rating: IP67
- Status indicator LED included
- Reverse polarity and short-circuit protection
- Dimensions (H x L x W): 30mm x 269mm x 30mm
- Weight: 0.5 kg
Key Features
- T-slot cylinder type compatible with round body, profile, tie-rod, dovetail groove cylinders and SMC rails
- Measuring range of 256 mm with housing length of 269 mm
- IO-Link output function with standard IO-Link V1.1 communication
- Electrical wiring: DC 4-wire with reverse polarity and short-circuit protection
- IP67 rated enclosure for dust and water protection
- Status indicator LED and teach-in functionality for easy setup
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Operating temperature range from -20 °C to +70 °C
- Cable with M12 male connector, 4-pin, 0.3 m length, PUR material
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connection and sensor calibration using teach-in functions.
Applications
- Industrial automation for precise cylinder position measurement
- Factory automation requiring robust and accurate linear position sensing
- Use in environments needing IP67 rated sensors with IO-Link communication
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient operation with low power consumption (25 mA without load)
- Durable design reduces waste and replacement frequency
- Complies with China-RoHS environmental standards
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-256TLTQ0 T-slot Cylinder Position Sensor is available for immediate purchase, ideal for industrial automation and factory applications requiring precise linear position measurement.
