Cylindrical Fuse 22x58mm | 690V AC | 50A | High Breaking Capacity by NHP

BRAND: NHP
SKU: FR22GG69V50
$17.40 List price: $23.10
+
Cylindrical fuse with 690V AC and 50A rating—ideal for electrical distribution systems. Built for high breaking capacity of 120 kA, ensuring safety and reliability in industrial and commercial applications.

Product Name/Title: Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 50A

Brand: NHP

SKU: FR22GG69V50

Alternatively Known As: Cylindrical Fuse, 22x58mm Fuse, 50A Fuse, Mersen Fuse

Technical Specifications
  • Utilization Category: gL/gG (cable protection/equipment protection)
  • Breaking Capacity AC: 120 kA
  • Breaking Capacity DC: 100 kA
  • Voltage Type: AC/DC
  • Rated Current: 50 A
  • Rated Voltage AC: 690 V
  • Rated Voltage DC: 250 V
  • Power Loss at Rated Current: 5.3 W
  • Model: Ceramic fuse
  • Dimensions (H x L x W): 58mm x 22mm x 22mm
  • Weight: 0.1 kg
Key Features
  • Cylindrical design for easy installation.
  • High breaking capacity of 120 kA for AC applications.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Electrical distribution systems
  • Industrial machinery protection
  • Commercial electrical installations
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
  • Reduces risk of electrical fires and equipment damage, promoting safety.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 50A is available now for immediate purchase. Ideal for electrical distribution and protection applications.

Non-Returnable & Non-Cancellable

FR22GG69V50-AU-Cylindrical-Fuse-Datasheet.pdf (FR22GG69V50-AU-Cylindrical-Fuse-Datasheet.pdf, 252 Kb) [Download]
