Cylindrical Fuse 22x58mm | 80A 690V AC | High Breaking Capacity | Easy Installation by NHP
Cylindrical fuse with 80A current and 690V AC voltage—ideal for electrical distribution systems. Built for industrial equipment protection, with high 120 kA breaking capacity and easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 80A
Brand: NHP
SKU: FR22GG69V80
Alternatively Known As: Cylindrical Fuse, Fuse 22x58mm, 80A Fuse
Technical Specifications
- Utilization Category: gL/gG (cable protection/equipment protection)
- Breaking Capacity AC: 120 kA
- Breaking Capacity DC: 100 kA
- Voltage Type: AC/DC
- Rated Current: 80 A
- Rated Voltage AC: 690 V
- Rated Voltage DC: 250 V
- Power Loss at Rated Current: 7.4 W
- Model: Ceramic fuse
- Dimensions (H x L x W): 58mm x 22mm x 22mm
- Weight: 0.1 kg
Key Features
- Cylindrical design for easy installation.
- High breaking capacity of 120 kA for AC applications.
- Rated for 80 A current and 690 V AC voltage.
Professional Installation Requirements
- Installation by a qualified electrician is recommended for safety and compliance.
Applications
- Electrical distribution systems
- Industrial equipment protection
- Commercial electrical installations
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Designed for efficient power management and reduced energy loss.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 80A is available now for immediate purchase. Ideal for electrical distribution and protection applications.
