DALI-2 LED Driver Kit | 1.2m Flex & Plug | 650mA Constant Current | Flicker-Free Dimming | by Ektor
The DALI-2 LED Driver Kit is designed for efficient LED lighting control, featuring a 1.2m flex and plug along with a constant current mode set to 650mA. Ideal for both commercial and residential applications, this driver ensures flicker-free dimming and operates within a wide input voltage range of 216Vac to 253Vac, making it a reliable choice for DALI-2 compatible systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: DALI LED Driver, DALI-2 LED Driver Kit, LED Driver with Flex and Plug, Constant Current LED Driver, DALI DT6 Driver
Technical Specifications
- Dimensions (H x L x W): 40mm x 70mm x 150mm
- Weight: 0.3 kg
Key Features
- DALI DT6 LED driver with full support for DT6 allowing flicker-free dimming
- Includes 1.2m 2 core flex and plug plus 2 core flying lead
- Constant current driver mode with selectable driver currents from 250mA to 1100mA
- Wide input voltage range of 216Vac to 253Vac (230Vac nominal)
- High power factor of 0.95 and low standby power consumption of 0.5W
- Surge protection of 2kV between line and neutral
- Operating temperature range from -20 to 50 °C
- Short Term Light Modulation (PstLM) and Stroboscopic Visibility Measure (SVM) well below required limits for flicker and stroboscopic effects
- Dimmable with compliant DALI-2 application controllers
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and safe operation.
Applications
- LED lighting control in commercial and residential buildings
- DALI-2 compatible lighting systems requiring flicker-free dimming
- Integration with compliant DALI-2 application controllers
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 61347.1
- AS/NZS 61347.2.13
- AS CISPR 15
Environmental Benefits
- Energy-efficient LED driver reduces power consumption
- Low standby power minimizes energy waste when lighting is off
- Flicker-free dimming improves lighting quality and reduces eye strain
Warranty Information
Standard manufacturer warranty applies. Please refer to Ektor for specific warranty terms.
Available Now
The Ektor DALI-2 LED Driver Kit is available now for immediate purchase. Ideal for commercial and residential LED lighting control applications requiring DALI-2 compatibility and flicker-free dimming.
