DALI-2 LED Driver Kit | 1.2m Flex & Plug | Constant Current 1000mA | by Ektor
The DALI-2 LED Driver Kit is designed for efficient LED lighting control, featuring a 1.2m flex and plug along with a 2 core flying lead. Ideal for both commercial and residential applications, this driver operates in constant current mode at 1000mA, ensuring flicker-free dimming and energy efficiency. With a robust surge protection of 2kV and a wide operating temperature range, it’s perfect for various indoor lighting installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: DALI-2 LED Driver Kit, Constant Current LED Driver, DALI LED Driver with Flex and Plug, Ektor DALI Driver
Technical Specifications
- Input Frequency: 50 Hz
- Input Current: 0.14 A
- Driver Power: 22.8 W
- Driver Current: 1000 mA (settable variants available)
- Output Voltage Range: 6-38 V
- Flex & Plug Length: 1200 mm
- Wiring Type: Flex and Plug (2 pin) and 2 wire flying lead (DALI)
- IC Rating: Do not cover
- Fitting Colour: White
- Dimensions (H x L x W): 40mm x 70mm x 150mm
- Weight: 0.3 kg
Key Features
- DALI DT6 LED Driver with full support for DT6 allowing flicker-free dimming
- Includes 1.2m 2 core flex and plug and 2 core flying lead
- Constant current driver mode
- Dimmable with compliant DALI-2 application controllers
- Surge protection of 2kV L-N
- Low standby power consumption of 0.5 W
- Operating temperature range from -20 to 50 °C
- Power factor of 0.95
- Input voltage range 216Vac - 253Vac (230Vac nominal)
- Short Term Light Modulation (PstLM) ≤ 0.011 ensuring minimal flicker
- Stroboscopic Visibility Measure (SVM) ≤ 0.005 minimizing visual discomfort
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and safety.
Applications
- Commercial and residential LED lighting control
- DALI-2 compatible lighting systems requiring flicker-free dimming
- Indoor lighting installations with constant current LED drivers
Standards & Compliance
- AS/NZS 61347.1
- AS 61347.2.13
- AS CISPR 15
Environmental Benefits
- Energy-efficient LED driver reduces power consumption
- Low standby power reduces energy waste during non-use
- Flicker-free dimming improves lighting quality and reduces eye strain
Warranty Information
Standard manufacturer warranty applies. Please refer to Ektor's warranty policy for details.
Available Now
The Ektor Driver Kit - DALI-2 LED driver with 1.2m 2 core flex and plug and 2 core flying lead set to 1000mA is available for immediate purchase. Ideal for commercial and residential LED lighting control applications.
