Trade Discount 17%
DALI-2 LED Driver Kit | 1.2m Flex & Plug | Constant Current 300mA | by Ektor
The DALI-2 LED Driver Kit is designed for efficient LED lighting control, featuring a 1.2m flex and plug along with a 2 core flying lead. With a constant current mode set to 300mA, this driver ensures flicker-free dimming and is perfect for both commercial and residential applications, providing reliable performance and energy efficiency.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: DALI-2 LED Driver Kit, Ektor DALI LED Driver, Constant Current LED Driver, DALI DT6 LED Driver
Technical Specifications
- Dimensions (H x L x W): 40mm x 70mm x 150mm
- Weight: 0.3 kg
Key Features
- DALI DT6 LED driver with full support for DT6 allowing flicker-free dimming
- Includes 1.2m 2 core flex and plug and 2 core flying lead (DALI)
- Constant current driver mode
- Dimmable with compliant DALI-2 controllers
- Surge protection of 2kV L-N
- Low standby power consumption of 0.5 W
- Operating temperature range from -20 to 50 °C
- Power factor of 0.95
- Input voltage range 216Vac - 253Vac (230Vac nominal)
- Short Term Light Modulation (PstLM) less than 1.0 for flicker control
- Stroboscopic Visibility Measure (SVM) less than 0.4 to reduce visual discomfort
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical standards and safe operation.
Applications
- LED lighting control in commercial and residential buildings
- DALI-2 compatible lighting systems requiring flicker-free dimming
- Integration with compliant DALI-2 application controllers
Standards & Compliance
- AS/NZS 61347.1
- AS 61347.2.13
- AS CISPR 15
Environmental Benefits
- Energy-efficient LED driver reduces power consumption
- Low standby power minimizes energy waste during non-operation
- Flicker-free dimming improves lighting quality and reduces eye strain
Warranty Information
Standard manufacturer warranty applies. Please refer to Ektor for specific warranty terms.
Available Now
The Ektor Driver Kit - DALI-2 LED driver with 1.2m 2 core flex and plug and 2 core flying lead set to 300mA is available for immediate purchase. Ideal for LED lighting control in commercial and residential applications.
