DALI-2 LED Driver Kit | 1100mA Constant Current | 1.2m Flex & Plug | Dimmable | by Ektor
The DALI-2 LED Driver Kit is designed for efficient LED lighting control, featuring a constant current output set to 1100mA and a 1.2m flex and plug for easy installation. Ideal for both commercial and residential applications, this driver ensures flicker-free dimming and operates within a wide temperature range of -20 to 50 °C, making it perfect for various lighting environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: DALI-2 LED Driver Kit, Constant Current LED Driver, DALI DT6 LED Driver, LED Driver with Flex and Plug
Technical Specifications
- Input Voltage: 230Vac (-6%/+10%)
- Input Frequency: 50 Hz
- Power Factor: 0.95
- Input Current: 0.25 A (at 1100mA setting)
- Driver Power: 41.8 W
- Driver Current: 1100 mA
- Output Voltage Range: 6-38 V
- Surge Protection: 2kV L-N
- Standby Power: 0.5 W
- Working Temperature Range: -20 to 50 °C
- Dimmable: Yes
- Wiring: Flex and Plug (2 pin) and 2 wire flying lead (DALI)
- Driver Mode: Constant Current
- Short Term Light Modulation (PstLM): 0.005
- Stroboscopic Visibility Measure (SVM): 0.007
- Dimensions (H x L x W): 30mm x 60mm x 120mm
- Weight: 0.3 kg
Key Features
- DALI DT6 LED Driver with full support for DT6 allowing flicker-free dimming
- Set to 1100mA constant current output
- Includes 1.2m 2 core flex and plug plus 2 core flying lead
- Wide working temperature range from -20 to 50 °C
- High power factor of 0.95
- Surge protection of 2kV L-N
- Low standby power consumption of 0.5 W
- Short Term Light Modulation (PstLM) less than 1.0 for reduced flicker
- Stroboscopic Visibility Measure (SVM) well below 0.4 to minimize visual discomfort
- Dimmable with compliant DALI-2 application controllers
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and proper integration with DALI lighting control systems.
Applications
- Commercial and residential LED lighting control
- DALI-2 compliant lighting systems requiring flicker-free dimming
- Indoor lighting installations with constant current LED drivers
Standards & Compliance
- AS/NZS 61347.1
- AS 61347.2.13
- AS CISPR 15
Environmental Benefits
- Energy-efficient LED driver reduces power consumption
- Flicker-free dimming improves lighting quality and reduces eye strain
- Low standby power consumption minimizes energy waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Ektor warranty terms for details.
Available Now
The Ektor Driver Kit - DALI-2 LED driver with 1.2m 2 core flex and plug set to 1100mA is available for immediate purchase. Ideal for commercial and residential LED lighting control applications requiring reliable and flicker-free dimming.
