Data Cable 1 Pair 0.22mm | LSZH Jacket | Grey Color | 500m Length | Per 100m by Eltech
Data cable with 1 pair conductor configuration and 0.22mm diameter—ideal for data transmission in industrial and commercial environments. Built for telecommunications and networking installations, featuring a low smoke zero halogen (LSZH) jacket for enhanced safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Data Cable 1 Pair 0.22mm 7/020 – Grey – Special – LSZH
Brand: Eltech
SKU: ELT7201P-ALT-GR
Alternatively Known As: LSZH Data Cable 1 Pair 0.22mm, Low Smoke Zero Halogen Data Cable, Instrumentation Data Cable Grey
Technical Specifications
- Conductor size: 0.22mm diameter, 7 strands of 0.20mm
- Number of cores: 1 pair
- Colour: Grey
- Drum length: 500 meters
- Minimum order quantity: 100 meters increments
- Jacket type: Low Smoke Zero Halogen (LSZH)
- Dimensions (H x L x W): 5mm x 500000mm x 5mm
- Weight: 2 kg
Key Features
- 1 pair conductor configuration
- Conductor size: 0.22mm (7 strands of 0.20mm)
- Low Smoke Zero Halogen (LSZH) jacket for enhanced safety
- Grey outer sheath for easy identification
Professional Installation Requirements
- Installation should be performed by qualified professionals following local electrical and safety codes.
Applications
- Data transmission in industrial and commercial environments
- Instrumentation and control systems
- Telecommunications and networking installations
Standards & Compliance
- Complies with AS/NZS 5000 series for cables and wiring
- Meets AS/NZS 3808 for low smoke zero halogen cables
Environmental Benefits
- LSZH jacket reduces toxic smoke and halogen emissions in case of fire, improving environmental and user safety
Warranty Information
Standard manufacturer warranty applies. Please refer to Eltech warranty policy for details.
Available Now
The Eltech Data Cable 1 Pair 0.22mm 7/020 Grey Special LSZH is available now for immediate purchase. Ideal for data and instrumentation cable applications requiring safety and reliability.
