Data Cable 10 Pair 0.22mm | LSZH Jacket | Grey Outer Sheath | 7/020 Stranding | Per 10m by Eltech

BRAND: Eltech
SKU: ELT7210P-ALT
$47.70 List price: $57.70
10 10m increments ($4.77 per 10m increments)
Free pick up (over 25 kg or over 1 meter)
For delivery quote message
30 Days Return Delivery Options
Data cable with 10 pair conductor configuration and LSZH jacket—ideal for telecommunications and networking applications. Built for professionals, it offers enhanced safety with low smoke emissions and flexibility for easy installation.

Product Name/Title: Data Cable 10 Pair 0.22mm 7/020 – Grey – Special – LSZH

Brand: Eltech

SKU: ELT7210P-ALT

Alternatively Known As: 10 Pair Data Cable, LSZH Data Cable, Instrumentation Cable, Grey Data Cable 10 Pair

Technical Specifications
  • Conductor Size: 0.22mm diameter
  • Stranding: 7 strands of 0.20mm
  • Number of Pairs: 10
  • Outer Colour: Grey
  • Minimum Order Quantity: 10 meters
  • Drum Length: 500 meters
  • Jacket Material: Low Smoke Zero Halogen (LSZH)
  • Dimensions (H x L x W): 10mm x 500000mm x 10mm
  • Weight: 4.5 kg
Key Features
  • 10 pair conductor configuration
  • Low Smoke Zero Halogen (LSZH) jacket for enhanced safety
  • Grey outer sheath for easy identification
  • 7/020 strand construction for flexibility
Professional Installation Requirements
  • Installation should be performed by qualified professionals to ensure compliance with electrical and safety standards.
Applications
  • Data transmission in telecommunications
  • Instrumentation and control systems
  • Networking and communication installations
Standards & Compliance
  • Complies with AS/NZS 5000 series for electrical cables and wiring
  • Meets AS/NZS 3808 for low smoke zero halogen cables
Environmental Benefits
  • LSZH jacket reduces toxic smoke and halogen emissions in case of fire
  • Environmentally safer material choice for indoor installations
Warranty Information

Standard manufacturer warranty applies, typically 1 year against defects.

Available Now

The Eltech Data Cable 10 Pair 0.22mm 7/020 Grey Special LSZH is available for immediate purchase, ideal for telecommunications and instrumentation applications.

Data Sheet (media.nl, 137 Kb) [Download]
