Data Cable 3 Pair 0.22 7/020 Special LSZH Grey Drum of 500m Eltech
Eltech Data Cable 3 Pair 0.22 7/020 Special LSZH in Grey. Drum of 500m. Ideal for data and communications installations.
Sign in
Please login to continue to your account.
- Conductor Size: 0.22mm (7 strands of 0.20mm)
- Number of Pairs: 3
- Colour: Grey
- Drum Length: 500m
- Minimum Order Quantity: 100m increments
- Jacket Type: Low Smoke Zero Halogen (LSZH)
- Dimensions (H x L x W): 8mm x 500000mm x 8mm
- Weight: 4.5 kg
- 3 pair conductor configuration
- Conductor size 0.22mm
- Low Smoke Zero Halogen (LSZH) jacket for enhanced fire safety
- Grey outer sheath for easy identification
- Available in 500m drum lengths
- Installation should be performed by qualified professionals following AS/NZS wiring and safety standards.
- Data transmission in industrial and commercial environments
- Instrumentation and control systems
- Low smoke zero halogen (LSZH) environments requiring fire safety
- Complies with AS/NZS 5000.1 for electrical cables
- Meets AS/NZS 3808 for low smoke zero halogen cables
- LSZH jacket reduces toxic smoke and halogen emissions in case of fire, improving safety and environmental impact
Standard manufacturer warranty applies. Please refer to Eltech warranty policy for details.
The Eltech Data Cable 3 Pair 0.22 7/020 Grey Special LSZH is available now for immediate purchase. Ideal for data and instrumentation cable applications requiring fire safety compliance.
Q: What makes the 3-pair configuration of this LSZH cable suitable for instrumentation and control systems?
A: The 3-pair layout of the Eltech ELT7203P-ALT provides additional circuit capacity compared to single or 2-pair variants, making it well suited to instrumentation and control system installations where multiple signal pairs are needed within a single cable run. The LSZH jacket also meets fire safety requirements for enclosed or occupied environments.
Q: Is this cable available in quantities smaller than a full 500m drum?
A: Yes — the Eltech Data Cable 3P LSZH Grey is sold in 500m drums but with a minimum order quantity of 100m increments, allowing you to order only what the job requires without committing to a full drum.
Where your wiring layout only requires minor path distribution, a 2-pair LSZH grey data cable offers a highly functional, lower pair count option for smaller multi-circuit runs.
For control applications requiring higher pair counts in the same LSZH format, integrating a 4-pair LSZH grey data cable provides the necessary capacity expansion.
If your installation only needs a single circuit path while retaining low-smoke performance, a standard 1-pair LSZH grey data cable is also available.
