DC Contactor 72A 24V with Integrated Diode | 3 NO & 1 NC Contacts | by Allen-Bradley
The DC Contactor 72A 24V is designed for efficient motor load switching, featuring an integrated diode for coil protection and a robust 72 Amp current rating. Ideal for industrial automation, this contactor ensures reliable control of DC powered equipment, making it perfect for electrical power circuits and motor control applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Current Rating: 72 A
- Coil Voltage: 24V DC
- Coil Type: Integrated diode for protection
- Contact Configuration: 3 normally open (NO) poles, 1 normally closed (NC) contact
- Termination: Line side coil termination with screw terminals
- Application: Motor load switching
- Dimensions (H x L x W): 90mm x 80mm x 70mm
- Weight: 1.5 kg
Key Features
- 72 Amp current rating
- 24V DC coil with integrated diode for coil protection
- 3 normally open poles
- 1 normally closed contact
- Line side coil termination
- Screw terminal connections
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper connection.
Applications
- Motor load control in industrial automation
- Switching electrical power circuits
- Control of DC powered equipment
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Integrated diode reduces coil voltage spikes, enhancing longevity and reducing electronic waste.
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 100C72DJ01 Contactor is available for immediate purchase, ideal for industrial motor control and automation applications.
