DC Miniature Circuit Breaker 125A | 20kA Breaking Capacity | 1P & 2P Configurations | Noark
DC miniature circuit breaker with a 125A current rating and 20kA breaking capacity—ideal for solar power installations and industrial DC systems. Built for safety and reliability, with compliance to IEC 60947-2 and UL 1077 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: B1E2P100
Brand: Noark
SKU: 1000676
Alternatively Known As: DC Miniature Circuit Breaker, DC MCB 125A, Noark DC Circuit Breaker
Technical Specifications
- Current Rating: 125A
- Breaking Capacity: 20kA
- Pole Configuration: 1P & 2P
- Rated Operating Voltage: 110VDC (1P), 250VDC (2P)
- Standards: IEC 60947-2, UL 1077
- Certifications: CE, UR, SAA
- Dimensions (H x L x W): 85mm x 70mm x 18mm
- Weight: 0.3 kg
Key Features
- Miniature Circuit Breakers up to 125A
- Tested according to IEC 60947-2 & UL 1077
- High rated breaking capacity up to 20kA
- Available in 1P & 2P configurations
- Rated operating voltage: 110VDC (1P); 250VDC (2P)
- Wide range of accessories
- Certifications: CE, UR, SAA
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with electrical safety standards.
Applications
- DC electrical systems requiring circuit protection
- Solar power installations
- Battery management systems
- Industrial DC power distribution
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances electrical safety reducing risk of fire and equipment damage
- Supports renewable energy systems by protecting solar and battery circuits
Warranty Information
Standard manufacturer warranty applies, typically 1-2 years against manufacturing defects.
Available Now
The Noark DC MCB 125AB1E B1E2P100 is available for immediate purchase, ideal for DC power protection in solar, industrial, and battery systems.
