DC Miniature Circuit Breaker 2P K25A | 600VDC | High Breaking Capacity | Non-Polarized by Noark
DC Miniature Circuit Breaker with 2P configuration and rated for 600VDC—ideal for solar power and industrial applications. Built for safety and reliability, featuring high breaking capacity up to 10 kA and non-polarized connection for flexible installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ex9BD125 2P K25A DC600V IEC
Brand: Noark
SKU: 90269
Alternatively Known As: DC Miniature Circuit Breaker, DC MCB 600V, Noark DC Circuit Breaker
Technical Specifications
- Non-polarized connection
- 1P & 2P versions available
- High-rated breaking capacity up to 10 kA
- Rated current up to 100A
- Rated operating voltage: 300VDC (1P), 600VDC (2P)
- Dimensions (H x L x W): 85mm x 70mm x 35mm
- Weight: 0.3 kg
Key Features
- Non-polarized connection for flexible installation
- Available in 1P and 2P versions
- High-rated breaking capacities up to 10 kA
- Rated current up to 100A
- Rated operating voltage: 300VDC (1P) and 600VDC (2P)
Professional Installation Requirements
- Installation should be performed by a qualified electrician experienced with DC electrical systems to ensure compliance and safety.
Applications
- DC electrical systems requiring circuit protection up to 600V DC
- Solar power installations
- Battery management systems
- Industrial DC power distribution
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Enhances safety and reliability in renewable energy systems
- Supports sustainable energy solutions by protecting solar and battery systems
Warranty Information
Standard manufacturer warranty applies, typically 1 year against manufacturing defects.
Available Now
The Noark DC MCB Ex9BD125 2P K25A DC600V IEC is available for immediate purchase, ideal for solar power and industrial DC applications.
