DC Miniature Circuit Breaker 2P K50A | 600VDC | High Breaking Capacity | Non-Polarized by Noark
DC Miniature Circuit Breaker with 2 poles and a rated current of 50A—ideal for solar power systems and industrial DC applications. Built for safety and reliability, it features a high breaking capacity of up to 10 kA and a non-polarized connection for flexible installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ex9BD125 2P K50A DC600V IEC
Brand: Noark
SKU: 90272
Alternatively Known As: DC Miniature Circuit Breaker, DC MCB 600V, Noark DC Circuit Breaker
Technical Specifications
- Non-polarized connection
- Available in 1P and 2P versions
- High-rated breaking capacity up to 10 kA
- Rated current up to 100A
- Rated operating voltage: 300VDC (1P), 600VDC (2P)
- Dimensions (H x L x W): 85mm x 70mm x 35mm
- Weight: 0.3 kg
Key Features
- Non-polarized connection for flexible installation
- Available in 1P and 2P versions
- High-rated breaking capacities up to 10 kA
- Rated current up to 100A
- Rated operating voltage: 300VDC for 1P and 600VDC for 2P
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with electrical safety standards and proper operation.
Applications
- DC electrical circuits requiring protection up to 600V DC
- Solar power systems
- Battery storage systems
- Industrial DC power distribution
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances safety and reliability of DC electrical systems, reducing risk of electrical faults and fires
- Supports renewable energy systems such as solar power by providing reliable DC circuit protection
Warranty Information
Standard manufacturer warranty applies, typically 1-2 years against manufacturing defects.
Available Now
The Noark DC MCB Ex9BD125 2P K50A DC600V IEC is available for immediate purchase, ideal for DC electrical protection in solar and industrial applications.
