Trade Discount 16%
DC Miniature Circuit Breaker 2P K63A | 600V DC | High Breaking Capacity | Non-Polarized Connection by Noark
DC Miniature Circuit Breaker with 2 poles and a rated current of 63A—ideal for solar power and industrial applications. Built for safety with high breaking capacity up to 10 kA and non-polarized connection for flexible installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ex9BD125 2P K63A DC600V IEC
Brand: Noark
SKU: 90273
Alternatively Known As: DC Miniature Circuit Breaker, DC MCB 600V, Noark DC Circuit Breaker
Technical Specifications
- Non-polarized connection
- 1P & 2P versions available
- High-rated breaking capacity up to 10 kA
- Rated current up to 100A
- Rated operating voltage: 300VDC (1P), 600VDC (2P)
- Dimensions (H x L x W): 85mm x 70mm x 35mm
- Weight: 0.3 kg
Key Features
- Non-polarized connection for flexible installation
- Available in 1P and 2P versions
- High-rated breaking capacities up to 10 kA
- Rated current up to 100A
- Rated operating voltage: 300VDC (1P) and 600VDC (2P)
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with electrical safety standards.
Applications
- DC electrical systems requiring circuit protection up to 600V DC
- Solar power installations
- Battery management systems
- Industrial DC power distribution
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances electrical safety reducing risk of fire and equipment damage
- Supports renewable energy systems such as solar power installations
Warranty Information
Standard manufacturer warranty applies, typically 1 year against manufacturing defects.
Available Now
The Noark Ex9BD125 DC MCB 2P K63A DC600V IEC is available now for immediate purchase. Ideal for DC electrical protection in solar and industrial applications.
