DC Motor for Ceiling Fan | 2.1m Length | Graphite Finish

BRAND: Mercator
SKU: FC479210GR
$326.80 List price: $434.60
+
DC motor for ceiling fans with a 2.1m length and graphite finish—ideal for efficient air circulation. Built for high airflow, compatible with 5-speed remote control and summer/winter settings.

Product Name/Title: DC Motor for Ceiling Fan | 2.1m Length | Graphite Finish

SKU: FC479210GR

Alternatively Known As: Ceiling Fan DC Motor, Rhino Ceiling Fan Motor, 2.1m Fan Motor, Graphite Ceiling Fan Motor

Technical Specifications
  • Motor Type: DC
  • Length: 2.1 meters
  • Maximum Air Movement: 16,836m³/hr
  • Blade Compatibility: 6 Aluminium blades (sold separately)
  • Remote Control: Compatible with 5-speed remote with summer and winter settings
  • Finish: Graphite
  • Dimensions (H x L x W): 200mm x 2100mm x 200mm
  • Weight: 3.5 kg
Key Features
  • Rhino 6B 2.1m DC Motor only
  • Compatible with Rhino 2.1 6-blade set (sold separately)
  • Available in Brushed Chrome, Graphite, and White finishes
  • Compatible with 5-speed remote control with summer and winter settings
  • Maximum air movement of 16,836m³/hr
Professional Installation Requirements
  • Professional installation by a qualified electrician or licensed ceiling fan installer is recommended to ensure safety and optimal performance.
Applications
  • Residential ceiling fans
  • Commercial ceiling fan installations
  • Indoor air circulation and cooling
Standards & Compliance
  • AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
  • Energy-efficient DC motor reduces power consumption compared to traditional AC motors.
Warranty Information

5 years motor warranty and 2 years in-home warranty.

Available Now

The Rhino DC Motor for Ceiling Fan in Graphite finish is available now for immediate purchase. Ideal for residential and commercial ceiling fan applications.


Ceiling Fan Sizing Calculator

This calculator uses typical airflow recommendations. Users must verify results according to AS/NZS 3000:2018 and specific manufacturer specs.
