Diamond Cutting Disc 115mm | Sintered Segment Connection | 13300 RPM Max Speed | by Wurth
The Diamond Cutting Disc 115mm is engineered for precision straight cuts in construction tasks. With a sintered segment connection for enhanced durability and a maximum rotation speed of 13300 RPM, this disc is perfect for use with angle grinders. Ideal for professionals seeking reliable performance, it ensures efficient cutting with minimal pressure required during operation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Diamond Cutting Disc 115mm | Sintered Segment Connection | 13300 RPM Max Speed | by Wurth
Brand: Wurth
SKU: 5527165115
Alternatively Known As: Diamond Cutting Blade, Diamond Saw Disc, Construction Cutting Disc, Angle Grinder Cutting Disc
Technical Specifications
- Diameter: 115 mm
- Bore hole diameter: 22.23 mm
- Segment height: 10 mm
- Segment thickness: 2.0 mm
- Segment connection: Sintered
- Max rotation speed: 13300 rpm
- Max circumferential speed: 80 m/s
- Versatility rating: 3 of 4 points
- Service life rating: 2 of 4 points
- Cutting speed rating: 2 of 4 points
- Cut quality rating: 3 of 4 points
- Dimensions (H x L x W): 10mm x 115mm x 115mm
- Weight: 0.2 kg
Key Features
- Highly versatile and cost-effective for construction use
- Designed for straight cutting only, not for lateral grinding
- Sintered segment connection for durability
- Max rotation speed of 13300 rpm and max circumferential speed of 80 m/s
- Segment height of 10 mm and thickness of 2.0 mm
- Requires no pressure during cutting; machine weight is sufficient
- Safety instructions must be followed including use of protective goggles and clothing
Professional Installation Requirements
- Clamping and installation must be performed by a trained specialist using clean clamping flanges of the same size. A test run is recommended to ensure safety.
Applications
- Construction site cutting tasks
- Straight cutting of various materials
- Use in angle grinders for precise cuts
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Long-lasting design reduces waste and frequency of replacements
- Efficient cutting reduces energy consumption during use
Warranty Information
Warranty against manufacturing defects as per Wurth standard policy.
Available Now
The Wurth Diamond Cutting Disc CUTDISC-DIA-CNST-T-BR22,23-D115MM is available now for immediate purchase. Ideal for construction and machining applications requiring precise straight cuts.
