Digital Time Switch 24 Hours + 7 Days | 230V AC | 16A Max | LCD Display by Clipsal
Digital time switch with 24-hour and 7-day programming, 230V AC voltage, and 16A max current—ideal for residential and small commercial applications. Built for energy efficiency, with manual override and 10-year backup.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Acti9, Digital Time Switch, 24 Hours + 7 Days
Brand: Clipsal
SKU: CCT15854
Alternatively Known As: Programmable Digital Timer, Weekly Timer Switch, Digital Time Controller
Technical Specifications
- Rated operational voltage: 230 V AC - 15...10 % at 50/60 Hz
- Minimum interval duration: 1 min
- Maximum switching current: 16 A - 250 V AC
- Accuracy: +/- 0.5 s/day at 25 °C
- Display type: LCD
- Battery type: Lithium
- Cycle duration: 24 hours + 7 days
- Dimensions (H x L x W): 90mm x 66mm x 18mm
- Weight: 0.09 kg
Key Features
- Automatically switches loads On and Off according to user-defined programs.
- Weekly switching cycle with 56 operations.
- Manual override capability.
- Backup time of 10 years for time and program saving.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments
- Commercial: Small commercial buildings
Standards & Compliance
- Complies with relevant Australian standards for electrical devices.
Environmental Benefits
- Energy-efficient design helps in reducing power consumption.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal Acti9 Digital Time Switch is available now for immediate purchase. Ideal for residential and small commercial applications.
