DIN Rail Main Switch 1 Pole 80A | 240V AC | IP40 Rated by NHP
DIN rail main switch with 1 pole and 80A rated current—ideal for residential, commercial, and light industrial applications. Built for safety and efficiency, with IP40 protection for indoor use.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Main Switch 1 Pole 80A
Brand: NHP
SKU: DTMSW180
Alternatively Known As: NHP Main Switch, DIN Rail Main Switch, 80A Circuit Breaker
Technical Specifications
- Rated Current: 80 A
- Number of Poles: 1
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: AC
- Rated Impulse Withstand Voltage: 4 kV
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 1-50 mm²
- Pollution Degree: 3
- Rated Surrounding Temperature: 35 °C
- Operating Ambient Temperature: -25 to 55 °C
- Dimensions (H x L x W): 85mm x 75.8mm x 17.5mm
- Weight: 0.09 kg
Key Features
- 1 Pole design for single-phase applications.
- Rated current of 80A suitable for various electrical loads.
- IP40 protection rating for indoor use.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Light industrial applications requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Efficient design reduces energy loss and enhances safety.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Main Switch 1 Pole 80A is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
