DIN Rail Main Switch 2-Pole 80A | 415V | IP40 Protection by NHP
DIN rail main switch with 2-pole design and 80A rated current—ideal for residential and commercial applications. Built for efficient circuit management, with IP40 protection for reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Main Switch 2Pole 80A
Brand: NHP
SKU: DINTMS802
Alternatively Known As: NHP 80A Main Switch, DIN Rail Main Switch, 2 Pole Circuit Breaker
Technical Specifications
- Rated Current: 80 A
- Number of Poles: 2
- Rated Voltage: 415 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Service Voltage: 12 V
- Rated Impulse Withstand Voltage: 8 kV
- Concurrently Switching Neutral Conductor: Yes
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 1-50 mm²
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -5-40 °C
- Dimensions (H x L x W): 86mm x 80mm x 36mm
- Weight: 0.24 kg
Key Features
- 2-pole design for efficient circuit management.
- Rated current of 80A suitable for various applications.
- IP40 protection rating for reliable performance.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Efficient energy management reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Main Switch 2Pole 80A is available now for immediate purchase. Ideal for residential and commercial applications.
