Discharge Muffler 311-14 | 7/8” ID Connection | Anti-Corrosion Finish | Harmonic Attenuator | by Aspen Pumps
The Discharge Muffler 311-14 is designed for industrial refrigeration systems, featuring a 7/8” ID connection and solid copper connectors. With an anti-corrosion powder coat finish and oil drain channels, it minimizes pressure drop and reduces noise, making it ideal for enhancing system efficiency and compliance with ISO/AS 5149.2 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Discharge Muffler 311-14 | 7/8” ID Connection | Anti-Corrosion Finish | Harmonic Attenuator | by Aspen Pumps
Brand: Aspen Pumps
SKU: 311-14
Alternatively Known As: Discharge Muffler 311-14, Harmonic Attenuator, Pressure Vessel Muffler
Technical Specifications
- Connection Size: 7/8” ID
- Lay-in Diameter: 280mm
- Safe Working Pressure (SWP): 4200 kPa
- Manufactured to ISO/AS 5149.2 standards
- Anti-corrosion powder coat finish
- Solid copper connections
- Compatible with models 311-14, 311-18, 311-22, 311-26, 311-32
- Features oil drain channels to prevent oil logging
- Dimensions (H x L x W): 280mm x 280mm x 280mm
- Weight: 3.5 kg
Key Features
- Connection: 7/8” ID with solid copper connectors
- Minimal pressure drop to improve plant efficiency
- Anti-corrosion powder coat finish
- Utilizes harmonic wave cut principles to reduce noise and smooth discharge pulse
- Oil drain channels to prevent oil logging
- Manufactured in accordance with ISO/AS 5149.2
Professional Installation Requirements
- Installation should be performed by qualified professionals familiar with pressure vessel and refrigeration system standards to ensure safety and compliance.
Applications
- Industrial refrigeration systems
- Pressure vessel discharge noise reduction
- Harmonic attenuation in compressor discharge lines
Standards & Compliance
- Complies with AS/NZS 5149.2 for refrigeration systems and pressure vessels
Environmental Benefits
- Reduces noise pollution in industrial environments
- Improves system efficiency by minimizing pressure drop
Warranty Information
Standard manufacturer warranty applies. Please refer to Aspen Pumps warranty policy for details.
Available Now
The Aspen Pumps Discharge Muffler 311-14 is available for immediate purchase, ideal for industrial refrigeration and pressure vessel applications.
