Double Control Input Auxiliary | 230-240V AC | DIN Rail Mount | IP20 by Clipsal

BRAND: Clipsal
SKU: A9C18308
$207.90 List price: $311.90
+
Double control input auxiliary with 230-240V AC voltage and DIN rail mounting—ideal for small commercial and residential applications. Built for reliable control, with IP20 protection and compact design.

Product Name/Title: Acti9, Double control input auxiliary

Brand: Clipsal

SKU: A9C18308

Alternatively Known As: Acti9 Double Control Input Module, Acti9 Auxiliary Switch

Technical Specifications
  • Control circuit voltage: 230...240 V AC 50/60 Hz.
  • Maximum output current: 0.2 A holding, 2 A inrush.
  • Hold-in power consumption: 3 VA.
  • Overvoltage category: III.
  • Rated insulation voltage: 440 V.
  • Rated impulse withstand voltage: 4 kV.
  • Dimensions (H x L x W): 81mm x 60mm x 18mm
  • Weight: 0.086 kg
Key Features
  • Fixed mounting mode on the left of CT.
  • DIN rail mounting support.
  • IP20 protection rating.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Small commercial and residential applications.
Standards & Compliance
  • Complies with IEC/EN 61095.
Environmental Benefits
  • Packaging without single-use plastic.
Warranty Information

18 months warranty.

Available Now

The Clipsal Acti9 Double Control Input Auxiliary is available now for immediate purchase. Ideal for small commercial and residential applications.
