Double Screw Connector 32Amp | 50Pcs Jar | Clear Housing & User Comfort | 240/415V by Cabac

BRAND: CABAC
SKU: HICDS-50
$19.60 List price: $23.80
+ −
30 Days Return Delivery Options
Heavy-duty insulated double screw connectors by Cabac, rated 32Amp for 240/415V applications, supplied in a 50 piece jar with clear plastic housing for easy visual inspection and user comfort.

Product Name/Title: Double Screw Connector 32Amp 50Pcs Jar

Brand: Cabac

SKU: HICDS-50

Alternatively Known As: Insulated Screw Connector, Electrical Screw Terminal, Double Screw Terminal Connector, 32A Screw Connector

Technical Specifications
  • Material Body: PVC
  • Connections: Brass
  • Voltage Rating: 240/415V
  • Amperage Rating: 32A
  • Accommodates up to 2 x 6mm² cables
  • One and two screw formats; two screw format for earth connection
  • Dimensions (H x L x W): 100mm x 100mm x 100mm
  • Weight: 0.2 kg
Key Features
  • Clear plastic housing allows visual inspection of termination
  • Soft plastic housing with no sharp edges for user comfort
  • Nominal 32A rating depending on conductor loading
  • Rated for normal 240/415V applications
  • Supplied in handy screw top jars
Professional Installation Requirements
  • Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards.
Applications
  • Used by electricians in junction boxes for general electrical connections
  • Connecting light fittings
  • General purpose wiring connections
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Durable materials reduce the need for frequent replacements
  • Clear housing enables easy inspection, reducing waste from faulty connections
Warranty Information

Standard manufacturer warranty applies. Please refer to Cabac warranty policy for details.

Available Now

The Cabac Double Screw Connector 32Amp 50Pcs Jar is available now for immediate purchase. Ideal for electrical wiring and general purpose connections in residential and commercial installations.
